OBC-900C Truck Tire Changer
- Product Description
- Installation Manual
-
Technical Parameter
Applicable rim size 14"-46" (Scalable to 56") Maximum wheel weight 1500kg Maximum wheel diameter 2300mm Applicable wheel width 1065mm Working pressure 17-18MPa Power supply 380V/220V Gearbox motor power 2.2kW/3.0kW Hydraulic pump motor power 2.2kw/1.5kw Weight of equipment 770kg Packing size L:2100*W:1700*H:1050(mm) Product introduction
● All tires of trucks, buses and engineering vehicles
Product characteristics● Use movable low-voltage control handle for operation. The console is lightWeight of equipment and easy to move
● Operating voltage is 24V, safe and stable
● The general assembly arm is equipped with a swinging assembly panel and assembly hook
● Tool support, lifting arm and fixture are hydraulic driven
● Cping force without adjustment
● The guide rail adopts the overall post-welding processing process, which eliminates the defects due to the welding processing deformation,ensures the accuracy of the guide rail, and makes the operation more stable
Scope of application
● This product is suitable for tires with a rim diameter of 14"-46" (up to 56")
Product quality
● EUCE certification
Key words:
OBC-900C Truck Tire Changer
