OBC-800C Car Tire Changer
- Product Description
- Installation Manual
-
Technical Parameter
Applicable rim size 10"-28" Maximum wheel diameter 1200mm Maximum wheel width 3"-12" Working pressure 9-10MPa Power supply 380V/220V/110V Gearbox motor power 1.1kw/1.5kw Hydraulic pump motor power 0.75kw/1.1kW Weight of equipment N.W.:366kg
G.W.:406kgPacking size L:1470*W:1050*H:1490(mm) Product introduction
● Hook wheel synchronization is an industry first. Simple structure, zero failure rate, reasonable Angle, wide disassembly range, can effectively complete the efficient disassembly of complex and difficult tires in a single plane, ergonomic and can achieve man-machine integration and other advantages. It is the simplest solution in the structure of the no-skid tire changing machine. This structure is independent intellectual property rights and the national invention patents.
Product characteristics
● While improving the efficiency ofusers, it greatly expands the range ofapplicable tires. it is the most suitableskid free product for the domestic market
● Structural advantages, seemingly simple and very clever, can be effectively completed in a single plane. The efficient disassembly of complex and difficult tires is the most ergonomic, with the hydraulic system, so that users fall in love with the operation
● Excellent electronic control system, automatically power off when stopping the operation, and the recovery operation starts since itself, while making it more humanized, but also taking into account many characteristics such as safety, energy saving, stability, efficiency and so on
● The hydraulic operation system is composed of cross switch and left and right control switch. With the middle column integrated system, the operation of the control machine is with ease
● After repeated changes of the disassembly head for a long time, the hydraulic system can make the disassembly head stably fixed in a point motionless, achieving the purpose of not hurting the tire or not hurting the wheel hub
● Optional servo motor, the speed of the variable speed motor is adjusted freely, from slow to fast, further improving the experience and efficiency of disassembly
Scope of application
● This product is suitable for all kinds of low, middle and high-end cars, SUV, special vehicle tires, no need to use a crowbar
Product quality
● EU CE certification
